DP502 FLUXWHITE
The Ultimate Thermal Performance for Gaming Cases
The DP502 FLUX White mid-tower gaming case is well equipped with an industry-leading design of advanced ventilation, taking the Antec Dark leaguegaming cases to the next generation.
Why the New Cooling
Solution?
When Intel announced their latest 10th Gen CPU and AMD announced their new Ryzen 3 and 4 CPUs, they all deliver remarkable performance upgrades and better productivity, it also means the functional requirement of PC equipment needs to be taken to the next level, especially the thermal performance.
To cope with the stress of enhanced heat dissipation, Antec developed a revolutionary structure for airflow, providing an improved and powerful cooling solution for your system. The F-LUX Platform.
Patented F-LUX Platform -
Antec's Original Cooling Solution
What is the F-LUX Platform? The definition of FLUX is Flow Luxury.
The F-LUX Platform is a new industry-leading and highly efficient design by Antec featuring
an advanced case structure for excellent airflow and 5 x 120 mm fans included.
A core element of the design ethos was to enhance GPU cooling performance.
F-LUX Platform - Antec's Original Cooling Solution
5 x 120 mm Fans Included
A
Motherboard Support: ATX , Micro-ATX, Mini-ITX
B
2.5” SSDs: 3
C
3.5” removable HDDs / 2.5” SSDs (Compatible): 3/2
D
3.5” removable HDDs / 2.5” SSDs (Compatible): 3/2
E
Max GPU Length: 405 mm (Supports high-end VGA, e.g. MSI GeForce, ASUS ROG)
F
Max CPU Cooler Height: 175 mm (Supports high-end CPU cooler, e.g. Noctua NH-U12A)
G
Max PSU Length: 205 mm
Sufficient space for Cable Management
Color Your System by Built-in LED Controller
You only need the LED mode button to control all the addressable LEDs.
Or you can sync it with the motherboard to enjoy more custom light effects.
The electroplating-processed LED on the top left-hand side presents a Sci-Fi vibe.
Easy to Clean
Make a Green Build
Keep It Clean
Keep It Clean
SPECIFICATIONS
Case Specification
Dimensions 463 x 220 x 486 mm (DWH)
Form Factor Mid Tower
Materials Steel + Plastic
Mainboard Support ATX, M-ATX, ITX
Front Access & Controls Power, LED Control Button, 2 x USB3.0, HD-AUDIO
Side Panel 4 mm Tempered Glass Side Panel
Expansion & Drive Bays
Expansion Slots 7
5.25" 1
3.5" /2.5"  3/2
2.5" 3
Fan
Front  3 x 120 mm / 2 x 140 mm
Top 3 x 120 mm / 2 x 140 mm (w/o ODD and w/o ODD bracket)
2 x 120 mm / 2 x 140 mm (w/o ODD but with ODD bracket)
2 x 120 mm / 1 x 140 mm (When ODD is installed)
Power Supply Shroud 2 x 120 mm
Rear 1 x 120 mm
Pre-installed Fans 3 x 120 mm fans in front
1 x 120 mm fan (Reverse Fan) on PSU shroud
& 1 x 120 mm fan in rear
Radiator Support
Front 120/240/280/360 mm  (≤ 55 mm thickness when fans are installed outside of front panel)
(≤ 30 mm thickness when fans are installed inside of front panel)
[Max Radiator Length ≤ 405 mm]
Top 240/280/360 mm  (w/o ODD and  w/o ODD bracket)
240/280 mm (w/o ODD but with ODD bracket)
120 mm(When ODD is installed)
[Max Radiator Length ≤ 405 mm]
Rear 120 mm
Clearance
Max GPU Length ≤ 405 mm
Max CPU Cooler Height ≤ 175 mm
Max PSU Length ≤ 205 mm
Miscellaneous
Dust Filter  Front / Top / Bottom / Right Hand Side
Net Weight 7.55KG
Gross Weight 8.7KG
Warranty  2 years
UPC# 0-761345-80051-8
